50W Fiber Laser Marking Machine for gold and silver cutting is a very hot sale usage. For some jewelry shop, they are starting to make customized jewelry for their clients to improve their jewelry profit, so today, we will show you our 50W fiber laser engraving cutting machine for both jewelry engraving and thin cutting,also photo engraving. 50W fiber laser engraving cutting machine is very multi function, so there is many customers buying it for small business at home. It's the best laser engraving machine for small business at home...
For 50 watts fiber laser marking machine, it has full function of common fiber laser 20W 30W marking machine, but also can work faster in metal deep engraving, what's the best is that it can do customized jewelry name laser cutting on gold silver brass and other jewelry materials. It can make customized name, letters, logos, photos engraving on all metals product surface.
1) Laser cutting on gold silver brass sheet to make their custom name jewelry.
2) Deep engrave on all metals, and do custom engraving on gift or some product to improve profit
1)For custom name jewelry laser cutting, they mostly laser cut gold silver, or brass, the thickness is mostly 0.8mm, maximum within 1.2mm. It can cut patterns in dxf ai and other vector file. so you can design by coreldraw or outo cad. About cutting time, it depends on the thickness of gold silver sheet and name size, for 0.5mm cutting, it usually takes about 4-6 minutes, for 0.8mm thickness, usually takes about 8-12 minutes, if 1-1.2mm, it will take around 13-16 minutes.
2)For metal engraving, such as Aluminum ,stainless steel ,carbon steel, its engraving depth can be 0.01-1.5mm by 50W fiber laser engraving machine.
Specifications of fiber laser engraving cutting machine for gold silver jewelry
|
Product model |
MZ-FMS50 |
MZ-FMS100 |
|
Type of machine |
Small 50 watts fiber laser cutting engraving machine for gold and silver jewelrye |
|
|
Laser Wavelength |
1064nm |
|
|
laser power |
50W |
100W |
|
Modulating frequency |
20KHz-100KHz |
|
|
Marking Range: |
110mm×110mm 175mm×175mm 210mm×210mm |
|
|
Repetition Precision |
±0.002 |
|
|
Marking mode |
static or dynamic |
|
|
Spot diameter |
0.025mm |
|
|
Lifting way of working table |
Manual or automatic |
|
|
Lifting height |
500mm |
|
|
Travel of table |
X:150mm Y: 90mm |
|
|
Machine power supply |
220V 50Hz 20A |
|
|
Cooling method |
forced-air cooling |
|
|
Power of the Whole Equipment |
<0.5KW |
|
|
working conditions |
temperature:13°C~29°C, humidity:5%~75%, free of dust and well ventilated |
|
|
Overall dimension |
760×720×750mm |
|
|
Machine weight |
45Kg |
|
If any other questions or for more information about our 50W fiber laser marking machine for gold silver jewelry engraving and cutting, just feel free to text me on whatsapp:+8614753226012 or email to hellomike612@naver.com
